最新版的C166/ST10 VX-Toolset  V3.0, V3.1 有那些新增項目

• IDE updated with Eclipse "Indigo" platform v3.7.1 and CDT v8.0.1
• Many Eclipse IDE enhancements that significantly improve the ease of use
  • Defining a project as the active one to which build and debug commands are applicable
  • Control of the C start code through a properties page
  • Control of the Linker-Script-Language file through a properties page, enabling easy configuration of memory and interrupt vector table settings
  • Many rearrangements that improve consistency and unambiguity in the menu structure
• Updated Infineon DAS drivers for the OCDS debug system
• Support for many new derivatives in the Infineon XE166 series and XC2000 family, including ICACHE equipped devices (check the release note for details)
• Updated SFR files for the L, U, N, and H series in accordance with Infineon's latest documentation
• Updated C++ compiler frontend
• Many improvements and bug fixes

       公佈版本完整的訊息可下載 Release Note

全部C166/ST10 Development Solution 介紹

• Integrated Development Environment based on Eclipse, enabling extensibility though plug-ins from third parties (e.g. for RTOS configuration or debugging)
• Efficient C, C++/EC++ compilers
  • Conforms (default) to ISO/IEC 9899:1999(E), as well as ANSI-C X3.159-1989
  • C++ compatible with ISO/IEC 14882:1998(E)
• Integrated static code analysis functionality in the C compiler for the following standards:
  • MISRA-C:1998 and MISRA-C:2004 guidelines
  • CERT C secure coding standard
• C/C++ libraries, run-time libraries, floating-point libraries provided in source code
• Application wide automatic near allocation for faster code, without the need to explicitly use memory qualifiers
• Highly effective code compaction optimization (reverse inlining), even allowing application wide code density optimizations
• Global type checking by compiler and linker for verification of types
• Powerful assembler and linker/locator, using a versatile linker-script-language
  • Enhanced memory layout editing control
• Project set up wizard to help you to configure a new project
• Conversion utilities for easy project migration from classic TASKING C166/ST10 toolset or from Keil™ C166 Development Tools
• Import wizard and refresh option for Infineon DAvE projects
• Integrated support for programming Flash memory
• Toolset generates ELF/DWARF 3.0 output for tool interoperability
• The toolset supports all C166 and all popular ST10 derivatives, such as:
  • Infineon Technologies: C16x, XC16x, XE162, XE164, XE167, XE169, XC22xx, XC23xx, XC27xx, E-Gold/X-Gold, as well as all their individual variants
  • Intel: E-Gold/X-Gold GSM Baseband ICs
  • IPextreme: C166S V1 core
  • STMicroelectronics: ST10x168, ST10x251, ST10x252, ST10x269, ST10x271, ST10x272, ST10x273, ST10x275, ST10x276, ST10x296, Super10 core, as well as all their individual variants
  • Micronas: SDA6000
  • Future new derivatives can easily be added to the toolset through a processor XML description file
• The TASKING C166/ST10 tools are acknowledged as the best in the market, having been the de facto standard worldwide for many years. With a market share of more than 90% in automotive, prominent OEM and Tier-1 companies rely on the quality of the TASKING tools

Integrated Debugger

• Three debugger engines are available for debugging in C++, C and assembly: Simulator, On-Chip (OCDS) and ROM monitor debugger
• Seamless integration of the debugger into the Eclipse IDE
• Simulator debugger is included with all product bundles
• Wizard to help you configure your project to run on an evaluation board
• On-Chip debugging is supported through a USB-JTAG adapter (miniWiggler) or a simple parallel cable for Infineon evaluation boards. The USB-JTAG miniWiggler is often provided with Infineon starter kits or integrated as on-board functionality on the starter kits. The miniWigglers are also available from Altium as option to the Premium package.
• For OCDS the TASKING debugger makes use of Infineon’s Device Access Server (DAS), which is provided with the toolset. DAS also allows remote debugging over a TCP/IP network
• The ROM monitor debugger is plug-and-play ready for many evaluation boards, and configurable to your own hardware. It allows debugging via serial port, and through TCP/IP over a remote PC
• OSEK kernel-aware debugging, ORTI 2.0 and 2.1 based
• A standalone "GUI-free" debugger is available for running scripts for automated tests

相關可支援C166/ST10 VX-Toolset 軟體開發工具介紹Third-Party Product Guide.

Hitex 開發板及開發工具, Lauterbach Trace32 開發工具同樣為陸傑科技代理。  (Infineon 原廠開發板亦可以透過Hitex 購買)

更多有關C166/ST10 VX-Toolset 資訊
