Power Architecture Software Development Tools



是一個全新的C Compiler 提供 Power Architecture 汽車電子微控器開發使用。因為Tasking 其它成功的軟體開發工具經驗，自從Freescale and ST Power Architecture 目前逐漸在汽車電子領域中展露頭角，許多客戶要求Tasking 可以恢復對PowerPC 架構的處理器繼續支援。Tasking 也針對最新的Freescale (Qorivva/5xxx) and STMicroelectronics SPC5 汽車電子晶片提供最新的C Compiler 支援。Altium Tasking 體會到客戶需要使用相容Tasking VX-Tool 的PowerPC Compiler 的困擾，也立即恢復對最新的汽車電子PowerPC 微處理器全面支援，包含多核心variants.A brand new C compiler等。

依賴自1977年以來數十年軟體開發工具的經驗，Tasking 很快速的推廣Power Architecture Compiler 於市面上，也成功的取得汽車電子開發商的信賴。以下有幾項特點提供開發者參考，使您的產品可以快速在市場中居於領先地位：

  • Stable and reliable code-generation
  • Industry-leading code-optimizations on both speed and size
  • Versatile Linker Script Language, offering maximum configurability
  • Fast (compile-link) build times of your project
  • Long-term support arrangements, enabling you to support your customers for the life-time of your products and beyond
  • Software security arrangements for guaranteed continuity
  • Legacy version support of "frozen" compiler versions
  • C compiler technology developed and fully owned by Altium, not relying on any third party IP or open source
  • Very active and focussed compiler development
  • Continuous compiler qualification against industry-standard test suites and real life applications, such as powertrain ECU code

     最新Power Architecture Compiler V2.1版新增加功能介紹

      • Further improved code optimizations
      • Support for e200z0, e200z3, e200z4, e200z6 and e200z7
      • Device support for MPC56x and SPC56 included
      • The compiler supports the caching of intermediate results to avoid full compilations
      • Global type checking implemented
      • Toolset fully integrated into Eclipse IDE now
      • New TASKING license management system

    詳細公佈的V2.1 版本完整的訊息可下載Release Note v2.1.

    2014年加強版整預訂以2014年第一 或者第二季可以完成，V2.2主要功能有

  • TM/MCS assembler support

  • Support for additional devices, including MPC57 members

  • On-chip debug support through debug probe

  • MISRA-C:2012 guidelines supported

    The Power Architecture Software Development Toolset

    新的PowePC 工具符合多種標準及代碼優化技術，基於客戶不斷的要求也持續進行改良。它提供一個高效能的C 編譯器、多核心的連接器、定位器以及模擬器。所有工具都已整合至Eclipse的IDE環境中，也可以以命令列的方式執行。

    IDE and C/C++ optimizing compilers
    • Integrated Development Environment (IDE) based on Eclipse
      • Plug-in that tightly integrates the Power Architecture toolset into the IDE
      • Enabling extensibility though plug-ins from third parties (e.g. for RTOS configuration or debugging)
    • C/C++ compilers with integrated static code analysis for MISRA C and CERT C
    • Conforming to many industry standards, including:
      • ISO/IEC 9899:1999(E), as well as ANSI-C X3.159-1989
      • MISRA C guidelines supported: MISRA-C:1998 and MISRA-C:2004
      • CERT C secure coding standard
      • ABI standard as defined by semiconductor vendor
      • ANSI/IEEE-754 floating point support
      • ELF/DWARF support for tool interoperability
    • C libraries, run-time libraries, floating-point libraries, several provided in source code
    • Advanced multi-core support
    • Code profiling support in the compiler for collecting application statistics, helping to identify areas that could benefit from efficiency improvements
    • Run-time error checking, helping to detect errors during program execution
    • A wide range of code optimization techniques, including TASKING's highly respected Code Compaction optimization
    • Functionally similar to other TASKING VX-toolsets, allowing for easier migration between architectures
    Assemblers, linker/locator, utilities
    • Power Architecure assembler
    • Dedicated assembler for GTM/MCS*
    • Versatile linker/locator script language
    • Powerful data/code overlaying facilities
    • Data/code section allocation
    • Automatic and user specified allocation in target memory
    • New make utility with support for parallel builds on multi-core systems, for faster compilations
    • Map file viewer enabling easy analysis of project builds
    Integrated Debugger
    • New debugger technology, fully integrated into Eclipse, ready for the latest industry debugging trends like multi-core application development
    • Debugging in C++, C and assembly through a simulator or on-chip debugger*
    • On-chip debugging is supported through a debug probe from one of our partners. This probe is also available directly from Altium*
    • Board support for popular standard evaluation boards*
    • Integrated support for programming flash memory*

    Supported Power Architecture devices

    Vendor Series
    Freescale Qorivva MPC55xx, MPC56xx, MPC57xx*
    STMicroelectronics SPC5 series

    最新支援版本PowerPC C Compiler 事項Altium announces new release of TASKING C compiler for Power Architecture

    TASKING PowerPC C Compiler 產品版本及產品編號

  • 各版本分為單機(Node Lock License, PC Windows), 單機網路分享(Floating License PC Windows) 及伺服器主機分享等版本。 目前提供標準版，2014年初期會完成專業版的供應。訂購連絡info.stc@superlink.com.tw

    Ordering codes (支援PC/ Windows，其它OS 支援請先連繫) Toolset試用版註冊下載
    07-200-170-804 Standard Edition VX-toolset for Power Architecture:
    C compiler, C++ compiler*, Eclipse IDE, GTM support*, simulator debugger
    07-200-170-806* Professional Edition* VX-toolset for Power Architecture:
    C/C++ compiler, Eclipse IDE, GTM support, simulator and on-chip debugger
    有備註"*" 部份為2014年會完成項目
    		•
