68K/ColdFire Software Development Tools



Tasking 的68k/ColdFire Software Development Toolset是唯一在市面支援Freescale 68k, 68328 DragonBall, CPU32 以及ColdFire 微處理器最具開發全面性及先進的開發軟體工具。Tasking 也持續加強高階的效能分析層級，提高程式設計效能，並推廣支援C++。

 最新 V10.0版新增加功能

    • Support for ColdFire and Dragonball variants
    • Enhanced Embedded Development Environment:
      • An explorer like treeview control allows simplified configuration of the TASKING tools and the target processor for the experienced as well as the novice user
      • Menu structure is now tuned according to the development work flow, offering an intuitive project management setup
      • A switch enables the TASKING classic style menu option for those used to the setup of previous versions
    • Overall improved look for CrossView Pro debugger
    • Support for P&E Microcomputer Systems BDM interface cable for ColdFire, such as USB Multilink and Cyclone MAX
    • CrossView Pro support for Freescale M5208EVB and M5213EVB, and Avnet MCF5282 Developer boards

 自Intermetrics Microsystems Software Inc. (IMSI) 時代起，Tasking 68K 就是最成功的開發軟體。最早的名稱為InterTools。Altium 目前還保留了這鄉些版本，如果您目前仍有舊版本的需求。詳細公佈的V10.0 版本完整的訊息可下儎What's New in v10.0 and the Release Notes.

完整的68K/ColdFire Development Toolset 功能介紹

Embedded Development Environment (EDE)

EDE supplies you with direct and easy access to all the tools needed for application development via a single user interface.

  • Provides an integrated environment to edit, build, debug, and test your application
  • Customizable working and application environment
  • Project set-up and management
  • Powerful language sensitive editor
  • Easy configuration of C compiler, C++/EC++ compiler, assembler, linker/locator and debugger
  • Automated make facility
  • Access to third party tools
Highly optimizing C/C++/EC++ Compiler

The compilers apply powerful optimization algorithms which combined with target specific code generation produces the most efficient code for your application.

  • ANSI C/C++ and Embedded C++
  • Conforms fully to ANSI C X3.159-1989 and the X3J16 C++ standard
  • C++ supports templates, dynamic casts, run-time type identification and exception handling
  • In-line assembly
  • Processor-specific runtime libraries, including source
  • 100% MASM (Motorola Assembly Language) compatible
  • Macro preprocessing
  • Multiple locator output formats
CrossView Pro Debugger

The debugger provides features and functionality to help shorten debugging sessions, test/verify applications and determine performance bottlenecks.

  • Multiple viewing windows, customizable window displays
  • Mixed-mode source/assembly display
  • "Bubble-Spy" to quickly examine variables and/or functions
  • Code, data and complex breakpoints
  • Assertions for hard to find errors
  • Direct memory and register access
  • Record and playback debug sessions
  • Debugging support for ROM monitors, simulators and BDM/JTAG
    • BDM/JTAG support for ColdFire through select P&E Micro wigglers/probes
    • BDM/JTAG support for CPU32 is no longer available
  • Program Performance Analysis through:
    • Code Profiling
    • Code Coverage
    • Graphical Data Analysis
  • RTOS aware debugging, incl. support for OSEK

Supported Freescale 處理器系列

Freescale 68K, DragonBall 68328, CPU32, and ColdFire processors:
MCF5204, MCF5206, MCF5206E, MCF5207, MCF5208, MCF5211, MCF5212, MCF5213, MCF5214, MCF5216, MCF5232, MCF5233, MCF5234, MCF5235, MCF5249, MCF5249L, MCF5270, MCF5271, MCF5272, MCF5274, MCF5274L, MCF5275, MCF5275L, MCF5280, MCF5281, MCF5282, MCF5307
MC68328, MC68EZ328, MC68VZ328, MC68SZ328
MC68302, MC68306, MC68330, MC68331, MC68332, MC68336, MC68340, MC68360, MC68F375, MC68376
MC68000, MC68HC000, MC68HC001, MC68EC000, MC68SEC000, MC68008, MC68010, MC68020, MC68EC020, MC68030, MC68EC030, MC68040, MC68EC040, MC68LC040, MC68V040, MC68060, MC68EC060, MC68LC060
CAST, Evatronix: Synthesizable Cores
C68000, C68000-AHB

Tasking 68K/ ColdFire Development Toolset 支援其它軟體工具(RTOS, Debugger ...)。PDF下載。

Hitex 開發板及開發工具, Lauterbach Trace32 開發工具同樣為陸傑科技代理。

TASKING 68K/ColdFire Development Toolset 產品版本及產品編號

各版本分為單機(Node Lock License, PC Windows), 單機網路分享(Floating License PC Windows) 及伺服器主機分享等版本。 詳細原廠資料下載。訂購連絡info.stc@superlink.com.tw

Ordering codes (支援PC/ Windows) 完整試用版註冊下載demo version.

07-200-001-012: EDE/Editor, C/C++/EC++ compiler, Assembler, Linker/Locator and CrossView Pro Simulator
07-200-001-024: EDE/Editor, C/C++/EC++ compiler, Assembler, Linker/Locator, CrossView Pro ROM monitor, BDM/JTAG & Simulator Debugger
Optional to 07-200-001-024:
xx-xx Macraigor Wiggler for CPU32 5V: No longer supported by and available from Macraigor
xx-xx Macraigor Wiggler for CPU32 3V: No longer supported by and available from Macraigor
07-292-001-003 P&E Micro BDM Interface for ColdFire 5V (incl. cable extension)
07-292-001-004 P&E Micro BDM Interface for ColdFire 3V (incl. cable extension)
07-292-001-005 P&E Micro BDM USB-MULTILINK interface for ColdFire 3V/5V
